Parallel & Combinatory chemistry

The principle of combinatorial chemistry, or high-throughput synthesis, allows for the simultaneous multiplication of reactions between molecules, speeding up the creation of a compound database or chemical library. It is crucial to bring different chemical compounds together at the same time or under varying reaction conditions, which necessitates a multi-reactor screening tool.

Parallel synthesis addresses the same need by saving time and differentiating compounds through multiple experiments performed simultaneously, allowing for a rapid study of reaction kinetics under pressure.

Combinatorial Chemistry Specifications

Specification

details

Product Screening

Yes

Autoclave Ramps

Up to 10 ramps with 10 autoclaves each

Operating Pressure

100 bars

Operating Temperature

Up to 200°C

Cooling

Rapid cooling available

Reactive Gas Introduction

Yes

Options

Mixture preparation, automatic sampling, filtration, and solid compression

Parallel Chemistry Specifications

Specification

details

Product and Process Screening

Yes

Reactor Units

2 to 8 reactors usable in parallel or with individual parameters

operating pressure

Up to 250 bars

operating temperature

Up to 250°C

unit volumes

15 ml to 1 liter

materials

Stainless Steel, Hastelloy, Inconel

Options

Agitation, pressure regulation, heating, cooling, controlled injection, gas consumption measurement, automatic sampling

Supervision

Supervision via LabVIEW
